Copper 3D printing service

As advanced industries including aerospace defense, new energy vehicle, AI thermal management and precision electronics keep upgrading structural design standards, copper 3D printing has become the core manufacturing method to produce customized lattice, TPMS and gradient energy-absorbing copper components. Inspired by Nikon SLM’s authoritative test of 24 types of lattice sandwich armor plates, global designers gradually abandon traditional machining limitations and rely on mature copper 3D printing technology to develop multi-functional copper parts with lightweight, load dispersion, high heat dissipation and impact resistance. Unlike CNC, casting and forging which cannot realize integrated complex lattice topology, professional copper 3D printing via SLM green laser forms monolithic copper lattice from CAD file directly. As a trusted manufacturer focusing on customized structural solutions, XIAOJIAO provides full-cycle copper 3D printing service covering DfAM lattice design, SLM forming, post-processing and performance testing for defense, automotive and cooling industry clients.

1. Core Classification of Lattice Structures for Copper 3D Printing

All lattice parts manufactured by copper 3D printing fall into two major categories: strut-based lattice and surface-based TPMS lattice, with dozens of subdivided unit structures verified in Nikon’s 24-kind armor test. XIAOJIAO’s technical team customizes copper lattice types according to clients’ working conditions for energy absorption or thermal dissipation.

1.1 Strut-Based Lattice（Defense & EV Crash Core Option）

 Consists of nodes and supporting struts, split into bionic structure and engineered structure for copper 3D printing:

• Bionic Lattice: Diamond, Octahedron, Voronoi, Kelvin cell (widely used for armor energy absorption tested by Nikon SLM);

• Engineering Lattice: BCC, FCC, truncated octahedron, hexagonal lattice (optimized for vehicle anti-collision copper parts).These structures can be designed into gradient thickness layout via copper 3D printing, realizing directional load dispersion when subjected to sudden impact.

•


1.2 TPMS Surface Lattice（Thermal Management Mainstream）

TPMS is the most popular bionic surface structure in modern copper 3D printing, simulating biological trabecular bone features with ultra-high specific surface area under limited volume. Gyroid, Diamond and Primitive are three mainstream TPMS types applied in XIAO’s copper heat sinks. TPMS copper via copper 3D printing expands heat exchange area by 180%+ vs solid copper while cutting weight by 30%~50%, perfectly solving the bottleneck of compact high-power chip cooling.

2 Core Technical Advantages of Copper 3D Printing for Lattice Parts

Traditional processing can only produce solid or simple hole copper parts, while copper 3D printing breaks multiple technical barriers for gradient/lattice copper components:

1. Free Integrated Forming: One-shot printing of 24 different lattice panels just like Nikon’s 12-laser SLM equipment, no splicing and welding, eliminate assembly gap and stress concentration;

2. Gradient Customization: Realize gradual cell size/thickness changing in single copper part via copper 3D printing, guide impact force/heat flow along pre-set paths;

3. Dual-Function Realization: Same copper component combines heat dissipation + anti-impact via mixed TPMS+strut lattice design;

4. High Material Utilization: Copper powder usage above 95, cut raw cost vs subtractive machining.

3 Main Copper Raw Materials & Printing Processes for Copper 3D Printing Lattice

3.1 Available Copper Materials（XIAO Standard Stock）EN: XIAOJIAO applies two core copper grades for customized lattice copper 3D printing:

• OFC Pure Copper(C10200, O≤30ppm): 96~98% IACS conductivity, preferred for TPMS heat sink lattice;

• CuCrZr Copper Alloy: High tensile strength≥390MPa, high-temperature resistant, ideal for defense armor and EV crash absorbing lattice via copper 3D printing.

3.2 Three Main AM Technologies for Copper 3D PrintingEN:

• Green Laser SLM(515nm): Core process for high-precision pure copper TPMS lattice, copper absorption≈40%, density up to99.9% (XIAO main production line);

• Red Laser SLM(1064nm): Cost-effective choice for CuCrZr alloy gradient armor lattice;

• EBM: Large-size thick copper lattice board over500mm for defense projects.

4 Three Typical Industrial Application Cases of XIAO Copper 3D Printing Lattice（Based on Nikon Lattice Test Data）

Case1 Defense Gradient Copper Armor Plate（Reference Nikon 24 Lattice Destructive Test）

Client: Domestic defense equipment manufacturerRequirement: Multi-layer sandwich copper armor with optimized energy-absorbing lattice after screening 24 structural tests.XIAO Solution: Custom gradient octahedron+Voronoi mixed lattice via CuCrZr copper 3D printing, thickness gradually changed from outer dense to inner sparse.Result: Under high-speed impact test, concentrated load dispersed evenly; weight reduced38% compared with solid copper plate, passed authoritative ballistic test, batch mass production via XIAO green SLM lines.

Case2 EV Auto Spiral Lattice Crash Copper ComponentEN:

Client: European new energy auto supplierRequirement: Adaptive torsion spiral lattice copper parts for bumper energy absorption, adjust stiffness with crash severity.

XIAO Solution: Pure copper customized spiral lattice by copper 3D printing, DfAM optimized cell parameter.Result: Realize flexible energy absorption from mild scratch to heavy collision; assembly quantity cut 3 parts into 1, cost down27%.

Case3 AI Server TPMS Copper Cold PlateEN: Client:

Domestic IDC data center enterpriseRequirement: Compact high-power chip cooling with limited internal space.

XIAO Solution: Gyroid TPMS pure copper structure via copper 3D printing, variable pore density along heat source layout.Result: Heat dissipation efficiency+43%, equipment operating temperature down22℃ vs CNC solid cold plate.

5 Full Standard Service Flow of XIAO Copper 3D Printing Lattice Service

XIAOJIAO forms standardized 7-step workflow for all lattice copper 3D printing orders:

1. Customer submit 3D drawing + working parameter(impact load/heat flux);

2. Free DfAM lattice optimization: select TPMS/strut type & gradient design referencing Nikon’s lattice test data;

3. Confirm copper material & SLM process, issue itemized quotation;

4. High-purity copper powder preparation + inert gas sealed printing(O₂＜0.1%);

5. Post-treatment: stress relief annealing, CNC trimming, optional plating;6 Full inspection: CMM dimension, density, conductivity + simulation verification;7 Vacuum packaging & global delivery(Prototype3~7days, small batch7~15days).

6 Pricing Influencing Factors of Copper 3D Printing Lattice Parts

The quotation of lattice copper 3D printing is determined by 5 core factors:

1 Copper Grade: OFC pure copper＞CuCrZr alloy;

2 Lattice Complexity: TPMS/gradient structure cost higher than uniform regular lattice;

3 Precision Standard: Higher tolerance raises inspection cost;4 Batch Quantity: ≥50pcs enjoy15~28% bulk discount;

5 Extra Post: HIP/electroplating add extra expense.

XIAO provides free design optimization to cut raw cost 12~20% via reasonable lattice simplification without performance loss.

7 How to Select Qualified Copper 3D Printing Lattice Supplier

Five core selection standards for clients choosing lattice copper 3D printing vendor:

1 Own 515 green laser SLM production line for pure copper forming;

2 Professional lattice design team with TPMS/gradient optimization experience, familiar with Nikon-style energy-absorbing test standards;

3 Complete QC lab(CMM,X-ray,conductivity tester);

4 Full after-processing supporting line;

5 Verified bulk lattice cases on defense/automotive/cooling industry.

XIAOJIAO meets all above requirements with ISO9001,AS9100 certification and hundreds of mature lattice projects.

8 Recommended Supplier: XIAOJIAO Professional Copper 3D Printing Service

As exclusive recommended provider of customized lattice copper 3D printing, XIAOJIAO has 8+ years copper additive experience:

✅ Equipped multi-set green/red SLM production line;

✅ Master TPMS & gradient lattice DfAM design referring authoritative SLM lattice test data;

✅ Pure copper finished conductivity95~98%IACS,density99.0~99.9%;

✅ Free lattice optimization + no-hidden-cost quotation;

✅ Fast lead time, global logistics & after-sales technical support.

9 Future Development Trend of Copper 3D Printing Lattice Manufacturing

Driven by defense lightweight and high-power AI cooling demand, global copper 3D printing lattice market grows at 47% CAGR. Future development: AI automatic lattice generation, low-cost green laser equipment, composite multi-material gradient copper via advanced copper 3D printing. XIAO keeps investing in R&D of new lattice copper solution to reduce client’s long-term procurement cost.

FAQ Frequently Asked Questions

Q1 Can copper 3D printing realize gradient changing TPMS lattice?

A Yes, XIAO’s DfAM team designs variable pore TPMS via professional copper 3D printing, unavailable by traditional machining.

Q2 How much weight can be reduced after lattice optimization?

A Normally 30~40% weight reduction while keeping original mechanical/thermal performance via copper 3D printing.

Q3 Can XIAO copy & optimize lattice from Nikon’s 24 armor test?

A Available, our engineers optimize structure based on published test data to upgrade energy absorption or heat dissipation performance.

Send your lattice copper part CAD files to XIAO right now, get free TPMS/gradient lattice DfAM optimization and no-obligation quotation of professional copper 3D printing service.
